Lifting Beam

The Conquip Lifting Beam is designed to transport any form of material that cannot be transported using a single point lift or a chain sling, or more than one item at a time.

The beam has two attachment points for connecting to a crane on the topside, and multiple points for attaching goods to be lifted on the underside.

Length

Hire/Purchase

Clear

SKU: N/A Category: Lifting Equipment

Description

FEATURES

Multiple lifting points on the underside ensure a safer, more stable lift.
Built-in stand.

BENEFITS

Ideal for transporting large, heavy or awkward loads.
The built-in stand prevents fouling of the hooks when it is landed and allows easy access to the attached lifting chains.
Tested and certified to a Factor of Safety 3.
Available in 3, 5 and 7-metre lengths as standard. Bespoke lengths can be made to order.

Specification

PRODUCT CODE	LIFTING POINTS	LENGTH (mm)	WIDTH (mm)	HEIGHT (mm)	WEIGHT (kg)	WLL* (kg)
CA233-05000	6	3000	473	817	170	5000
CA235-05000	10	5000	473	817	260	5000
CA237-05000	12	7000	473	817	350	5000

* Working Load Limit.

CA233-05000, CA235-05000, CA237-05000

Single-Leg Chain Sling

A high weight capacity, durable, hard-wearing lifting chain sling.

User Guide

Customer Support Video

Supporting Documentation

I need a length of beam longer than 7 metres. Can you help?

We offer 3, 5 and 7-metre lengths as standard but bespoke sizes are available on request.

How safe is this beam?

Our Lifting Beam is tested and certified to a Factor of Safety 3 for peace of mind with every lift.

How do I store the beam when not in use without damaging it?

There’s a built-in stand which stops damage to the hooks when it’s landed and allows easy access to the attached lifting chains.
