ibc lifting frame with ibc container in it front view
ibc lifting frame
ibc lifting frame
ibc lifting frame
ibc lifting frame with ibc container in it side view
ibc lifting frame
ibc lifting frame with ibc container in it front view
ibc lifting frame
ibc lifting frame
ibc lifting frame
ibc lifting frame with ibc container in it side view

IBC Lifting Frame

A lifting frame for crane lifting Intermediate Bulk Containers (IBC).

It is designed for a 4-point lift and can easily facilitate moving water and other liquids around site for use in different locations.

Typical uses can include carrying water to the top floor of a concrete slab for spraying down the slab during the curing process, for a wet-curing method.

Quantity
SKU: N/A Categories: , Tags: , , ,

Details

  • Complete with crane lifting points and fork pockets for easy manoeuvrability.
  • The latching bar, at the top of the frame, pivots on one side to allow for easy placement of the IBC into the frame.
  • Latching chain provides extra security.
  • Manufactured in the UK from quality British and EU steel.

Specification

PRODUCT CODE HEIGHT LENGTH WIDTH WEIGHT WLL*
CA148-01000 1550mm 1470mm 1270mm 250kg 1500kg

*Working Load Limit
