Autolock Tipping Skip
The faster, easier and safer method of transporting waste material. The Conquip Autolock Tipping Skip is the choice for many sites and leading plant companies. Designed for use with forklifts and telehandlers, these skips are heavy-duty to withstand the daily rigours of construction sites and thoroughly tested to ensure they are built to last.
A gas assisted ram ensures automatic locking of the skip to the forks and its unique design guarantees 100% restraint on the forks. The skip is emptied by adjusting the angle of the telehandler’s forks.
Description Autolock system eliminates the need to attach safety restraint chains. Utilising the telehandlers’ tilt function to tip the load ensures that the Autolock cannot be accidentally tipped. No levers or cables are required to discharge the Autolock so the driver can remain safely seated within the cab. Standard width fork pockets reduces the need for adjustment of forks. Raked-back design prevents damage to the skip. Designed and manufactured with quality British and EU steel. Can be painted in the Institute of Civil Engineers standard colours. Typical applications of the Autolock Tipping Skip:
House building – transportation of building materials around the siteSite waste management – transportation of waste materials to a larger skipInterior fit-out & refurbishment – easy movement of materials within a building, compact size allows for transportation through standard door frameSpecification PRODUCT TYPE PRODUCT CODE HEIGHT WIDTH LENGTH FORK POCKETS (W x H) WLL* WEIGHT CAPACITY Standard Autolock FA800-00500 934mm 920mm 1400mm 142 x 62mm 1000kg 120kg 500 litres With Castors FA801-00500 1023mm 989mm 1400mm 142 x 62mm 1000kg 165kg 500 litres Cranelift CA128-00500 1050mm 920mm 1400mm 142 x 62mm 1000kg 120kg 500 litres Cranelift with Castors CA134-00500 1138mm 989mm 1400mm 142 x 62mm 1000kg 170kg 500 litres Standard Autolock FA800-01200 964mm 1224mm 1818mm 142 x 62mm 2000kg 160kg 1200 litres With Castors FA801-01200 1051mm 1224mm 1818mm 142 x 62mm 2000kg 160kg 1200 litres Cranelift CA128-01200 1078mm 1224mm 1818mm 142 x 62mm 1000kg 160kg 1200 litres Cranelift with Castors CA134-01200 1160mm 1224mm 1818mm 142 x 62mm 1000kg 160kg 1200 litres
*Working Load Limit
